1 Technical Description, Installation Guidelines, Operation
28
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Keypad
The mode can be changed using the control buttons. You configure the underlying
AS-i line interactively with the display using the control buttons.
The following buttons are located on the front panel of the IE/AS-i LINK:
Display
The graphic display has a resolution of 128 x 64 pixels.
You configure the underlying AS-i line using the keypad and the display. This
allows on-site commissioning and diagnostics.
The following display appears after turning on the device and if there has been no
input over the keypad for a longer period of time (see Section 4.4).
Figure 1-5 Display − Logo
Note
If a fault occurs during operation, the resulting error message will be displayed
even if the Logo was previously displayed.
