Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

8 Using the Data Record Interface
125
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Table 8-4 AS-i Line Calls
Name
Function Index
(deci-
mal)
Data in the send or
receive buffer
Description
Store_Actual_Parameters Write 7 − Section 8.2.1.1
Store_Actual_Configuration Write 10 − Section 8.2.1.2
Set_LPS Write 12 LPS Section 8.2.1.3
Get_LPS_LAS_LDS_LPF_Flags Read 84 LPS, LAS, LDS, LPF,
flags
Section 8.2.1.4
Get_LAS_CDI_PI_Flags Read 85 Entire configuration
(LAS, CDI,
parameters), flags
Section 8.2.1.5
Set_LPS_PCD_PP_Flags Write 86 Entire configuration
(LPS, PCD,
parameters), flags
Section 8.2.1.6
Set_Operation_Mode Write 17 Mode Section 8.2.1.7
Set_Offline_Mode Write 18 Mode Section 8.2.1.8
Change_Slave_Address Write 20 Slave addresses Section 8.2.1.9
Set_Auto_Addr_Enable Write 21 Mode Section 8.2.1.10
Write_Extended_ID-Code_1 Write 24 ID1 code Section 8.2.1.11
Read_AIDI Read 25 Analog input data Section 8.2.1.12
Write_AODI Write 26 Analog output data Section 8.2.1.13
Read_AS-i_Line_Errorcounters Read 96 Error counters Section 8.2.1.14
Read_and_delete_AS-i_Line_Errorcoun-
ters
Read 97 Error counters Section 8.2.1.15
