Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
81
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
5.2.13 Navigation “AS-i Line 1 −> Overview”
All the information in this section also applies to AS-i line 2. With a single master,
the line number is not displayed.
5.2.13.1 Lifelist
Keypad/Display
AS-i Line 1 > Lifelist (displays all detected slaves)
Description of the follow-on menus as of Section 5.2.14.2
WBM: “Lifelist” Tab
Parameter Function
0(A) − 31(A);
1B to 31B
Addresses of the slaves 1−31 (slave 0 = reserved). If you have A/B slaves, these
are displayed extra in a second table.
Status Displays the status of the slaves (activated, missing, wrong/extra)
