8.2.1.15 Read_and_Delete_AS-i_Line_Errorcounters
Meaning
The call works in the same way as “Read_AS-i_line_error_counter”. On
completion, the AS-i master also sets all error counters to 0.
Structure of the RecordDataRead service − Index 97
Byte Meaning
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Version_hi = 0x00
1 Version_lo = 0x00
2 High byte
3
AS-i Power Fail
Low byte
4 High byte
5
Ground short
Low byte
6 High word / high byte
7
Summator:
High word / low byte
8
Summator:
Slave failure
Low word / high byte
9 Low word / Low byte
10 High word / high byte
11
Summator:
High word / low byte
12
Summator:
Missing slave frame
Low word / high byte
13 Low word / Low byte
14 High word / high byte
15
Summator:
High word / low byte
16
Summator:
Bad slave frame
Low word / high byte
17 Low word / Low byte
18 High word / high byte
19
Summator:
High word / low byte
20
Summator:
Slave I/O error
Low word / high byte
21 Low word / Low byte
22 High word / high byte
23
Summator:
High word / low byte
24
Summator:
Slave protocol error
Low word / high byte
25 Low word / Low byte
