Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

A AS-Interface Protocol Implementation Conformance Statement (PICS)
183
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Table A-2 , (Fortsetzung)
No. Comment / Function implemented by / see
Section
M4Function or Call on the Host Interface
(symbolic representation)
7 Status = Store_Actual_Parameters() X see Section 8.2
8 Status =
Set_Permanent_Configuration(Addr,
Config)
X see Section 8.2
9 Status, Config =
Get_Permanent_Configuration(Addr)
X see Section 8.2
10 Status = Store_Actual_Configuration() X By keypad and display; also with a call
(see Section 8.2)
11 Status, Config =
Read_Actual_Configuration(Addr)
X see Section 8.2
12 Status = Set_LPS(List31) X see Section 8.2
13 Status, List31 = Get_LPS() X see Section 8.2
14 Status, List31 = Get_LAS() X see Section 8.2
15 Status, List32 = Get_LDS() X see Section 8.2
16.0 Status = Get_Flags() X see Section 8.2
16.1 Status, Flag = Get_Flag_Config_OK() X see Section 8.2
16.2 Status, Flag = Get_Flag_LDS.0() X see Section 8.2
16.3 Status, Flag =
Get_Flag_Auto_Address_Assign()
X see Section 8.2
16.4 Status, Flag =
Get_Flag_Auto_Prog_Available()
X see Section 8.2
16.5 Status, Flag =
Get_Flag_Configuration_Active()
X see Section 8.2
16.6 Status, Flag =
Get_Flag_Normal_Operation_Active()
X see Section 8.2
16.7 Status, Flag = Get_Flag_APF() X see Section 8.2
16.8 Status, Flag = Get_Flag_Offline_Ready() X see Section 8.2
16.9 Status, Flag = Get_Flag_Periphery_OK() X see Section 8.2
17 Status = Set_Operation_Mode(Mode) X By keypad and display;
also with a call (see Section 8.2)
18 Status = Set_Offline_Mode(Mode) X see Section 8.2
19 Status = Activate_Data_Exchange(Mode) − optional call
20 Status = Change_Slave_Address(Addr1,
Addr2)
X see Section 8.2
21.1 Status = Set_Auto_Address_Enable X see Section 8.2
21.2 Status = Get_Auto_Address_Enable X see Section 8.2
22.1 Status, Resp =
Cmd_Reset_ASI_Slave(Addr, RESET)
− optional call
