A AS-Interface Protocol Implementation Conformance Statement (PICS)
184
IE/ASINTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000G8976C21603
Table A-2 , (Fortsetzung)
No. Comment / Function implemented by / see
Section
M4Function or Call on the Host Interface
(symbolic representation)
22.2 Status, Resp =
Cmd_Read_IO_Configuration(Addr,
CONF)
X see Section 8.2
22.3 Status, Resp =
Cmd_Read_Identification_Code(Addr,
IDCOD)
X see Section 8.2
22.4 Status, Resp = Cmd_Read_Status(Addr,
STAT)
X see Section 8.2
22.5 Status, Resp =
Cmd_Read_Reset_Status(Addr,
STATRES)
optional call
22.6 Status, Resp =
Cmd_Read_Ext_ID-Code_1(Addr,
IDCOD1)
X see Section 8.2
22.7 Status, Resp =
Cmd_Read_Ext_ID-Code_2(Addr,
IDCOD2)
X see Section 8.2
23 Status, S_List = Get_LPF() X see Section 8.2
24 Status =
Write_Extended_ID-Code_11(S_Ext_ID-C
ode_1)
X see Section 8.2
25 AImage, Status = Read_AIDI() X see Section 8.2
26 Status = Write_AODI(AImage) X see Section 8.2
27 String, Status = Read_ParamStr(S_Addr) X see Section 8.2
28 Status = Write_ParamStr(S_Addr, String) X see Section 8.2
29 String, Status = Read_DiagStr(S_Addr) X see Section 8.2
30 String, Status = Read_IdentStr(S_Addr) X see Section 8.2
Part B Supported Slave Profiles
1 Support of extended address mode X
2 Support of Combined transaction type 1
integrated (S-7.3 only)
X
3 Full support of Combined transaction
type 1 integrated
X Only profiles 7.3/7.4 are supported.
4 Support of Combined transaction type 2
integrated
X
5 Support of Combined transaction type 3
integrated
X
6 Support of Combined transaction type 4
integrated
X
