5 Display / WBM Configuration
95
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
or
AS-i Line 1 > Slave Info > Display... (select slave and “OK”)
Config. > Change configuration
...
Select a slave with the cursor buttons in the “Lifelist” or “Info” menu. Pressing “OK”
opens the “Config.” menu.
From the “Configuration” menu, use the cursor buttons “right”/“left” to change to
the other menus “Parameters”, “Bin. I/O”, “Analog” etc. With the “up”/“down” cursor
buttons, you change to the next slave. The “OK” button opens the follow-on menu
in which you can change the values. Exceptions: The “Status” and “Statistics”
menus have no display function.
Change the values with the “up”/“down” cursor keys. To transfer the changed
values to the slave, press the “OK” button.
WBM: “String Transfer” Tab
Parameter Function
Command You can choose from the following calls:
S Read_Identification_String; with profile 7.4
S Read_Diagnostic_String; with profile 7.4
S Read_Parameter_String; with profile 7.4
S Write_Parameter_String; with profile 7.4
S Read/Write_CTT2_String; with profile 7.5.5, 7.A.5, B.A.5
Send buffer Enter the slave data to be sent
Receive
buffer
Display of the received slave data.
This box can take up to 200 bytes and line breaks where necessary.
