Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
83
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Parameter Function
Slave Slave address
Error Slaves on which errors occurred marked red.
AS-i Power Fail Number of power supply failures on the AS-Interface
AS-i short to
ground
Number of ground shorts on the AS-Interface
Show Enables/disables the display of the corresponding error.
Error Shows how many errors of this type occurred (see Section 8.2.1.14).
The following errors are listed:
S Slave failure
S Missing slave frame
S Bad slave frame
S Slave I/O error
S Slave protocol error
S Bad master frame
