8 Using the Data Record Interface
123
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Device-specific errors of the link for the “Status” return value
Table 8-3 Error Detection in “STATUS[4]” of the Return Value of the IE/AS-i LINK
STATUS[4]
Meaning
01H Invalid CTT2 index
02H Invalid CTT2 length
04H CTT2 slave is temporarily busy.
05H The addressed AS-i slave was not found on the AS-Interface.
06H An AS-i slave with address 0 exists.
07H An AS-i slave with the new address already exists on the AS-Interface.
08H The AS-i slave address cannot be deleted.
09H Error reading the extended ID1 code
0AH The AS-i slave address cannot be set.
0BH The AS-i slave address cannot be stored permanently.
21H The AS-i slave address is incorrect
22H The AS-i slave is not activated (not in LAS).
23H Error on the AS-Interface
24H The call not permitted in the current status of the AS-i master.
25H An AS-i slave with address 0 exists.
26H The AS-i slave has illegal configuration data (I/O or ID codes).
27H The target address is not plausible (for example a B slave address was used for a
standard slave).
2EH The job number or the job parameter is unknown.
2FH The AS-i master has detected an EEPROM error.
31H A length error has occurred transferring a string.
32H A protocol error has occurred transferring a string.
33H CTT2 slave not initialized.
FFH Error not specified in greater detail
You will find other, general error IDs in the Help on SFB54.
