8 Using the Data Record Interface
146
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Table 8-7 Access to Analog Values of an AS-i Line using Data Records
AS-i slave address
Initial addresses for analog values in
data record 25 or 26
1 2
2 10
3 18
4 26
5 34
6 42
7 50
8 58
9 66
10 74
11 82
12 90
13 98
14 106
15 114
16 122
17 130
18 138
19 146
20 154
21 162
22 170
23 178
24 186
25 194
26 202
27 210
28 218
29 226
30 234
31 242
Examples of access:
Access to analog channel 1 of slave 7 has an offset of 50.
Access to analog channel 1 of slave 30B has an offset of 238.
