1 Technical Description, Installation Guidelines, Operation
18
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Convection
Make sure that you leave at least 5 cm clearance above and below the module to
allow heat dissipation.
Caution
The DIN rail may only be installed horizontally.
The IE/AS-i LINK must be mounted vertically to ensure the required heat dissipa-
tion through the ventilation openings and at the top of the device.
