5 Display / WBM Configuration
65
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Parameter Function
C-PLUG status The status of the C-PLUG is displayed here. The following statuses are possible:
S ACCEPTED
There is a C-PLUG with a valid and suitable content inserted in the device.
S C-PLUG has wrong device group
Invalid or incompatible content of the inserted C-PLUG. This status is also
shown if a C-PLUG of another device type was inserted.
S CRC ERROR
A C-PLUG with bad content is inserted.
S NOT FOUND
There is no C-PLUG inserted in the device.
C-PLUG
device group
Specifies the device group of the SIMATIC NET product line that was written to the
C-PLUG.
C-PLUG device
type
Specifies the device type of the SIMATIC NET product line that was written to the
C-PLUG.
Configuration
revision
Specifies the version and configuration structure. This information relates to the
configuration options supported by the device. This does not relate to the concrete
hardware configuration. This information can change when you run a firmware
update.
Type Shows the type of the C-PLUG file system.
Size Shows the maximum storage capacity of the C-PLUG file system.
Currently in use Shows the storage space in use in the C-PLUG file system.
C-PLUG
information string
Shows information about the device of the SIMATIC NET the product line that
previously used the C-PLUG, for example order number, type designation, version
of hardware and software (string display box).
Move configuration If you are logged on, you can make the following settings here:
S Internal Memory −> C-PLUG
The configuration in the internal memory of the device is moved to the C-PLUG.
This is followed by a restart.
Use case:
The device starts up with a C-PLUG inserted. The C-PLUG contains a valid
configuration that differs, however, from the configuration in the internal memory
of the IE/AS-i LINK. With this function, you can overwrite the content of the
C-PLUG with the original device configuration still stored on the IE/AS-i LINK.
S C-PLUG −> Internal Memory
The configuration in the C-PLUG is moved to the internal memory of the IE/AS-i
LINK.
Use case:
You want to remove the C-PLUG from the device. Before removing the C-PLUG,
move the configuration from the C-PLUG to the internal memory of the device.
You will then need to restart the IE/AS-i LINK manually (power OFF/ON).
Apply Apply the settings selected in “Move configuration”.
