Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

5 Display / WBM Configuration
90
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
WBM: “Diagnostics” Tab
This page displays all the relevant data of the selected slave.
Parameter Function
Detected If the slave is detected, a check mark is set here.
IO Display of the IO code of an AS-i slave
ID Display of the ID code of an AS-i slave
ID1 Display of the extended ID1 code of an AS-i slave
ID2 Display of the extended ID2 code of an AS-i slave
