Description
1.3 Key definition of the full CNC keyboard (vertical format)
Surface grinding
14 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
Hot keys
In the part program editor and in the input fields of the HMI, the following functions can be
carried out with certain shortcut keys on the full CNC keyboard:
Shortcut key Function
<CTRL> and <C> Copy selected text
<CTRL> and <B> Select text
<CTRL> and <X> Cut selected text
<CTRL> and <V> Paste copied text
<CTRL> and <P> Generates a screenshot of the actual screen and
saves the image on CompactFlash Card
(customer CF Card) under "screen802dsl.bmp "
<CTRL> and <R> HMI restart
<CTRL> and <S> Data backup in case of backlight failure
The series start-up archive (Drive/NC/PLC/HMI)
is exported with the most recent data onto the
CompactFlash card with the name
"802Dslibn.arc".
<ALT> and <L> Toggling between only upper case letters and
upper and lower case letters
<ALT> and <H> or <HELP> key Call help system
<ALT> and <S> Switch-in and switch-out the Editor for Asian
characters
