Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
317
&RS\
56
6HQG
Data Backup
12
12.1 Data transfer via RS232 interface
Functionality
The RS232 interface of the control system can be used to output data (e.g. part programs) to
an external data backup device or to read in data from there. The RS232 interface and your
data backup device must be matched with each other.
Operating sequence
You have selected the <PROGRAM MANAGER> operating area and you are in the overview
of the NC programs already created.
Select the data to be transmitted using either the cursor or the "Select all" softkey,
and copy the data to the clipboard.
Press the "RS232" softkey and select the desired transfer mode.
Figure 12-1 Reading out a program
Press "Send" to start the data transfer. All data copied to the clipboard will be transmitted.
