System
8.2 SYSTEM - "Start-up" softkeys
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
115
6WDUWXS
1&
3/&
+0,
The NC and PLC data are backed up. The drive data are not backed up.
Note
Saved data can be called via the following operator action:
• Press the <SELECT> key while the control system is booting.
• In the setup menu, select "Reload saved user data".
• Press the <Input> key
Note
Data that have been backed up can be called again from the operating area <SYSTEM> >
"Start-up" > "Power up with backed up data"!
8.2 SYSTEM - "Start-up" softkeys
Commissioning
Use this softkey to select the NC power-up mode.
Select the desired mode using the cursor.
● Normal power-up
The system is restarted
● Power-up with default data
The display machine data are reset to their standard values (restores the initial state
when originally supplied)
● Power-up with backed up data
The system restarts with the data that were last backed up (see Backup data)
The PLC can be started in the following modes:
● Restart
● Memory reset
Furthermore, it is possible to link the start with a subsequent debugging mode.
Selects the power-up mode of the HMI.
