9.9 Dressing and profiling - CYCLE416
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
175
9.9 Dressing and profiling - CYCLE416
Programming
CYCLE416 (Y_AB, Z_AB_L, Z_AB_R, F_DL_AB, F_BL_AB, F_DR_AB, F_BR_AB, F_Z_AB,
N_ABR, GWPS, N_AWST)
Parameter
Table 9- 5 Parameters of CYCLE416
Parameter Data type Meaning
Y_AB REAL Dressing amount in Y (incr.)
Z_AB_L REAL Dressing amount in Z, left/front (incr.)
Z_AB_R REAL Dressing amount in Z, right/rear (incr.)
F_DL_AB REAL Feedrate in the diameter direction, left
F_BL_AB REAL Path feedrate, left
F_DR_AB REAL Feedrate in the diameter direction, right
F_BR_AB REAL Path feedrate, right
F_Z_AB REAL Dressing feedrate in Z
N_ABR INT Number of dressing strokes
GWPS REAL GWPS
N_AWST INT Number of workpieces before dressing
Function
This cycle is used for dressing wheels with a path dresser.
Following each dressing stroke, the dressed amount is taken into account in the wear
parameters of the current tool offset.
Dressing is performed in accordance with workpiece counter _GC_WKS.
Sequence
Dressing involving setup cycles for the path dresser dressing method (CYCLE432).
