Cycles
9.5 Z positioning with grinding wheel - CYCLE406
Surface grinding
164 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
To add a cycle call to the program, carry out the following steps one after the other:
● From the horizontal softkey bar, selection bars for the individual cycles can be selected
using the <Grinding cycles> softkey.
● To select a cycle, keep using the vertical softkey bar until the appropriate input screen
plus help display appears on the screen.
● Number values can be directly entered. Entered values are verified for proper range.
● Some parameters that may have only a few values are selected using the toggle key.
● Press <OK> to complete your input (or <Abort> in case of error).
Recompiling
Recompiling of program codes serves to make modifications to an existing program using
the cycle support.
Position the cursor on the line to be modified and select the <Recompile> softkey. This will
reopen the corresponding input screen from which the program piece has been created, and
you can modify and accept the values.
9.5 Z positioning with grinding wheel - CYCLE406
Programming
CYCLE406 (N_SITZ, CLEAR, CAL, Z_LPOS, MODE, Y_POS, Z_POS, ZSTW, A_Z, F_LU,
F_SR, N_FR, FX, XSTART, XENDE)
Parameter
Table 9- 1 Parameter CYCLE406
Parameter Data type Meaning
N_SITZ INT Seat number
CLEAR INT Deletes the old offset prior to the approach
CAL INT Sets axis to Z position at end
Z_LPOS INT Retraction direction
