Siemens SINUMERIK 802D sl User Manual

Cycles
9.7 3-stage plunge cut oscillation (roughing, finishing and fine-finishing) - CYCLE408
Surface grinding
168 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
9.7 3-stage plunge cut oscillation (roughing, finishing and fine-finishing)
- CYCLE408
Programming
CYCLE408 (N_SITZ, XSTART, XEND, YEND ZEND, KS, Y_A_LU, Y_A_SR, Y_A_SL,
Y_A_FS, Z_A_LU, Z_A_SR, Z_A_SL, Z_A_FS, LUZ, SRZ, SLZ, FSZ, N_SR, N_SL, N_FS,
D_SR, D_SL, D_FS, ESL, EFS, FX_SR, FX_SL, FX_FS, FR)
Parameter
Table 9- 3 Parameters of CYCLE408
Parameter Data type Meaning
N_SITZ INT Seat number
XSTART REAL X axis starting position (abs)
XEND REAL X end position
YEND REAL Y end position
ZEND REAL Z end position
KS INT Acoustic emission sensor
Y_A_LU REAL Air grinding allowance (incr.)
Y_A_SR REAL Roughing allowance (incr.)
Y_A_SL REAL Finishing allowance (incr.)
Y_A_FS REAL Fine-finishing allowance (incr.)
Z_A_LU REAL Air grinding allowance (incr.)
Z_A_SR REAL Roughing allowance (incr.)
Z_A_SL REAL Finishing allowance (incr.)
Z_A_FS REAL Fine-finishing allowance (incr.)
LUZ REAL Air grinding feedrate, per stroke
SRZ REAL Roughing feedrate, per stroke
SLZ REAL Finishing feedrate, per stroke
FSZ REAL Fine-finishing feedrate, per stroke
N_SR INT Sparking-out strokes following roughing
N_SL INT Sparking-out strokes following finishing
N_FS INT Sparking-out strokes following fine-finishing
D_SR INT Dressing strokes prior to roughing
D_SL INT Dressing strokes prior to finishing
D_FS INT Dressing strokes prior to fine-finishing
ESL INT Relief after roughing
EFS INT Relief after finishing
FX_SR REAL X feedrate, roughing
FX_SL REAL X feedrate, finishing
