Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
31
2))6(7
3$5$0
7RROOLVW
Setup
4
4.1 Entering tools and tool offsets
Functionality
The "OFFSET PARAM" operating area allows you to store the parameters required for
machine operation.
Operating sequences
This function opens the "Tool offset data" window which contains a list of the tools created.
Use the cursor keys and the <Page Up>/<Page Down> keys to navigate in this list.
Figure 4-1 Tool list
To input the offsets, position the cursor bar on the tool to be changed and press the <Tool
data> softkey.
