10.2 Positional data
Surface grinding
222 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
10.2.10 Workpiece clamping - settable work offset: G54 to G59, G500, G53, G153
Functionality
The settable work offset specifies the position of the workpiece zero on the machine (offset
of the workpiece zero with respect to the machine zero). This offset is determined upon
clamping of the workpiece into the machine and must be entered in the corresponding data
field by the operator. The value is activated by the program by selection from six possible
groupings: G54 to G59.
Note
Workpiece clamping at an angle is possible by entering the angles of rotation around the
machine axes. These rotation portions are activated with the offset G54 to G59.
For information on operation, see Section "Setting/changing the work offset"
Programming
G54 ; 1st Settable zero offset
G55 ; 2nd Settable zero offset
G56 ; 3rd Settable zero offset
G57 ; 4th Settable zero offset
G58 ; 5th Settable zero offset
G59 ; 6th Settable zero offset
G500 ; Settable zero offset OFF - modal
G53 ; settable zero offset OFF non-modal, also suppresses programmable offset
G153 ; As with G53; additionally suppresses base frame
