Siemens SINUMERIK 802D sl User Manual

Part programming
7.4 Free contour programming
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
93
7.4 Free contour programming
7.4.1 Free contour programming (surface grinding)
Functionality
Free contour programming is a support tool for the editor. The contour programming function
enables you to create simple and complex contours.
A contour program editor (FCI) calculates any missing parameters for you as soon as they
can be obtained from other parameters. You can link together contour elements. Additional
contour transition elements are also available.
The programmed contours are transferred to the edited part program.
Note
The display MD 290 $MA CTM_POS_COORDINATE_SYSTEM defines the display of the
coordinate system.
A value of 7 means:
Ordinate = Y axis
Abscissa = Z axis
Technology
The contour calculator for milling technology provides the following functions for this
purpose:
● Chamfer/radius at the start and end of the contour
Start screen of the contour editor (FKE)
You have opened a part program in the <PROGRAM MANAGER> operating area.
