Siemens SINUMERIK 802D sl User Manual

Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
21
Software user interface
2
2.1 Screen layout
6WDWXVDUHD
$SSOLFDWLRQDUHD
7LS
DQGVRIWNH\DUHD
Figure 2-1 Screen layout
The screen is divided into the following main areas:
● Status area
● Application area
● Note and softkey area
Status area







Figure 2-2 Status area
