Siemens SINUMERIK 802D sl User Manual

System
8.6 SYSTEM - "Start-up files" softkeys
Surface grinding
148 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
&XVWRPHU
&)FDUG
5&6
FRQQHFW
56
● Data (in text format)
These data are special initialization data and are transferred in an ASCII file.
– Machine data
– Setting data
– Tool data
– R parameters
– Work offset
– Leadscrew error compensation
– Sag compensation
– Global user data
● Commissioning archive (drive/NC/PLC/HMI)
These data constitute a commissioning file for HMI data and are transferred in the binary
format using the HMI archive format.
– Drive machine data
– NC data
– NC directories
– Display machine data
– Leadscrew error compensation
– Sag compensation
– PLC project
– HMI data and applications
● PLC project (*.PTE)
A direct exchange between the control system and programming tool is possible without
conversion with the support of PLC project handling in the programming tool export
format.
● File for license key
Reading-in and reading-out data on a CompactFlash Card (CF card).
Reading-in and reading-out data to a PC via a network. The RCS tool must be installed on
the PC (only for SINUMERIK 802D sl pro).
Note
The RCS tool provides a detailed online help function. Refer to this help menu for further
details e.g. establishing a connection, project management etc.
Reading-in and reading-out data via the RS232 interface.
