Programming
10.4 Spindle movement
Surface grinding
256 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
Programming via spindle number
Some spindle functions can also be selected via the spindle number:
S1=..., S2=... ; Spindle speed for spindle 1 or 2
M1=3, M1=4, M1=5 ; Specifications for direction of rotation, stop for
spindle 1
M2=3, M2=4, M2=5 ; Specifications for direction of rotation, stop for
spindle 2
M1=40, ..., M1=45 ; gear stages for spindle 1 (if available)
M2=40, ..., M2=45 ; gear stages for spindle 2 (if available)
SPOS [n] ; Position spindle n
SPI(n) ; Converts spindle number n to axis identifier,
; e.g. "SP1" or "CC"
; n must be a valid spindle number (1 or 2)
; The functions of spindle identifiers SPI(n) and Sn are
identical.
$P_S[n] ; Last programmed speed of spindle n
$AA_S[n] ; Actual speed of spindle n
$P_SDIR[ n ] ; Last programmed direction of rotation of spindle n
$AC_SDIR[ n ] ; Current direction of rotation of spindle n
2 spindles installed
The following can be interrogated in the program via the system variable:
$P_NUM_SPINDLES ; Number of configured spindles (in the channel)
$P_MSNUM ; Number of programmed master spindle
$AC_MSNUM ; Number of the active master spindle
