Automatic mode
6.1 Automatic mode
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
71

%DFN
%ORFN
VHDUFK
7R
FRQWRXU
7R
HQGSRLQW
:LWKRXW
FDOFXODW
,QWHUU
SRLQW
)LQG
5H
JULQG
6LPXOWDQHRXV
UHFRUGLQJ
&RUUHFW
SURJUDP
Use this softkey to close the screen.
Use the block search function to go to the desired program location.
Forward block search with calculation
During the block search, the same calculations are carried out as during normal program
operation, but the axes do not move.
Forward block search with calculation to the block end point
During the block search, the same calculations are carried out as during normal program
operation, but the axes do not move.
Block search without calculation
During the block search, no calculation is carried out.
The cursor is placed on the main program block of the interrupt point.
The "Find" softkey provides the functions "Find line", "Find text" etc.
Use this softkey to display the "Regrinding" window.
Enter the offset values for regrinding. When you select <OK>, the parameters will be
inserted in the program after the selected block.
It is possible to simultaneously record when the part program is being executed (see Chapter
"
Simultaneous recording (Page 77)").
Use this softkey to correct a fault program passage. Any changes will be stored immediately.
