Automatic mode
6.4 Block search
Surface grinding
76 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
5H
JULQG
The search term can be entered with the following functions:
● "Text"
The systems jumps to the line with the corresponding text.
A toggle field is provided to define from which position you will search for the term.
● "Block no."
The cursor is positioned at the line with the "Line number".
Search result
The required part program block is displayed in the "Block display" window.
Note
For "Execute externally", no block search is possible.
Regrinding
"Regrinding" enables you to remachine the "seat" of a workpiece that has already been
machined, either with or without an offset, but always with the same technological values.
Use this softkey to display the "Regrinding" window.
Figure 6-9 Regrinding
Enter the offset values for regrinding.
