Programming and Operating Manual (Milling)
254 6FC5398-4DP10-0BA1, 01/2014
7. Enter the parameters for this element and press this softkey to select the desired contour
characteristics.
● Direction of rotation: counter-clockwise
● R: 9.5
● I: 0 abs.
● RND: 2
8. Press this softkey to confirm.
9. Press this softkey to select a contour element of straight line in any direction.
10. Enter the parameters for this element and press this softkey to confirm.
● α1: -30 °
11. Press this softkey to select a contour element of circular arc.
12. Enter the parameters for this element and press this softkey to select the desired contour
characteristics.
● Direction of rotation: clockwise
● R: 2
● J: 4.65 abs.
13. Press this softkey to confirm.
14. Press this softkey to select a contour element of circular arc.
15. Enter the parameters for this element and press this softkey to select the desired contour
characteristics.
● Direction of rotation: counter-clockwise
● R: 3.2
● I: 11.5 abs.
● J: 0 abs.
16. Press this softkey to confirm.
17. Press this softkey to select a contour element of circular arc.
18. Enter the parameters for this element and press this softkey to select the desired contour
characteristics.
● Direction of rotation: clockwise
● R: 2
● J: -4.65 abs.
19. Press this softkey to confirm.
20. Press this softkey to select a contour element of straight line in any direction.
