4 Machine 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
4-52 SINUMERIK 840C, OEM Version for Windows (BA)
With the data selector, however, it is also possible to select a specific program
for processing from the NCK memory and put it in the "program pointer".
Press the softkey SELECT PROG./JOB. Use the cursor keys to select the NCK
entry in the open data selector.
When you press the INPUT key the program types available in the NCK
memory are displayed. The following are available:
- ..
- MDA
- MPF
- SPF
Now position the selection cursor on the program type you wish to select (e.g.
MPF) and press the INPUT key. This action lists all the main programs in the
NCK memory.
Fig. 4-27 Select program
Now select the program you require with the CURSOR keys and press the
softkey SELECT PROG./JOB.
The program is put in the "program pointer" and can be processed by pressing
NC START.
Operating
sequence
Select
prog./job
Select
prog./job
