6 Programming 01.99
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
6-55
6.3.5 Machining cycles
Press the softkey for the cycle required (e.g. turning).
STOCK R. THREAD DRILL GROOVE UNDERCUT
DRILLING
CYCLES
DRILLING
PATTERNS
MILLING
CYCLES
MILLING
PATTERNS
The machining cycles are described in detail in a separate document
SINUMERIK 840 C Cycles
Programming Guide
6.3.6 Plane
Press the PLANE softkey.
Switch over to the desired channel.
Press the softkey for the desired plane, e.g. G18.
Press the STORE PLANE softkey.
After entering the channel number via the keyboard and selecting the plane
G17, G18 and G19, via a softkey, the abscissa, ordinate and applicant fields
and the two interpolation parameters are filled in automatically by the control.
You can also define a 4th axis. You can select the leading sign for the 3rd and
4th axes using the toggle fields.
Turning
Drilling and.
milling
Turning cycles
Drilling/Milling
cycles
Plane
1 ... n
...
G18
plane
Store
plane
