5 Parameters 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
5-24 SINUMERIK 840C, OEM Version for Windows (BA)
• The cams are combined in pairs. A pair of cams consists of a positive cam
and a negative cam. The area above the positive cam position is assigned to
the positive cam area and the area on the axis below the negative cam
position is assigned to the negative cam area.
• The positive and negative cams combined in a cam pair always refer to one
NC axis.
• After cam positions have been changed, you must first activate a signal
"Transfer of cam values" with an operating sequence (see manufacturer’s
documentation) before the changes become effective.
5.3.6.9 Cycle setting data
Press the ETC key to extend the SETTING DATA softkey bar.
You select CYCLE SETTING DATA.
The first display for cycle setting data (system data) appears on the screen.
Cycle setting data are separate for each channel. They are grouped into four
system and user areas:
Table 5-1 Overview of cycle setting data
0
.
99
System data Reserved
400
.
499
User data Free
800
.
849
System bits Reserved
900
.
949
User bits Free
Use of the reserved system data is described in the corresponding cycle
descriptions.
Cycle
data
