Siemens SINUMERIK 840C - Selecting the Machine Area

01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-3
4.1 Selecting the machine area
Press the DATA AREA key to activate Area Switchover.
Fig. 4-1 Area Switchover
When Area Switchover is selected:
• Press the MACHINE softkey to display the machine area
or press the MACHINE AREA key.
You can press the MACHINE AREA key at any time to activate the machine
operation window (i.e. to bring it into the foreground).
M
