01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-29
4.2.5.4 Creating a TEACH IN program in the edit mode
• The block structure has been set
• The axes have been selected
• Position the cursor in front of the last L
F
.
Press the GENERATE BLOCK softkey.
An NC block is generated at the cursor position according to the selected block
structure and the selected axes or entry in the input line (see examples).
1) With "Axis selection" screen
traversed
Axes
Axis selection
X
Y
Z
A
yes
yes
no
yes
Fig. 4-9 Axis selection screen
If axes X, Z and/or A have been traversed during the teach-in, the axis
positions are entered in the program with "Accept position". If a selected axis
has not been traversed, the position is not accepted.
Generated NC blocks:
without traversing movement
N10 L
F
with traversing movement on axes X and Y
N10 X = 100 L
F
The axis position of the Y-axis is not entered in the block as it has not been
selected.
Preconditions
Operating
sequence
Generate
block
Example 1
