4.3.2 Extended overstore
Machine manufacturer
The softkey function "Extended overstore" must be configured by the machine
manufacturer.
"Extended overstore" makes it possible to overstore by executing whole NC
program blocks or a single NC program.
With this function, traversing blocks or programs are executed when a channel
is in the RESET or stop state by inserting MDA mode without making a mode
change or RESET necessary. The program state and point of interruption are
"noted". The overstore program is processed and processing is then continued
from the point of interruption.
N20
N25
N30
N10
N15
.
.
.
The blocks prepared before the interruption
are traversed as if no interruption had taken place.
N1
N2
NC STOP, select "Extended overstore"
"Inserted"
program blocks
MDA1
%1234
%1234
• The machine area is selected.
• The mode group and channel in which you wish to overstore are selected.
• One of the modes JOG, TEACH IN or AUTOMATIC is selected.
• The program must be stopped with NC STOP or RESET.
NC STOP is activated either by pressing the NC STOP key or defined by
single block, program step, etc.
