01.99 6 Programming
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
6-56 SINUMERIK 840C, OEM Version for Windows (BA)
Use the selection key to select the options in the toggle fields.
You can use the leading sign settings for the 3rd and 4th axes to decide on the
use of the angle head mill. For example the following blocks are generated in
the part program:
Output of a 4th axis: G16 X Z Y+ X-
No 4th axis defined: G16 X Z Y
By pressing the STORE PLANE softkey, you transfer the selected plane into
the part program. In addition, the axes are correctly determined in the input
display of the CONTOUR DEFINITION and CYCLES function.
On selecting the G16 plane, you enter the values marked in the input display
via the keyboard.
By pressing the STORE PLANE softkey, you transfer the G16 plane into the
part program. You then additionally enter the axis names in the part program.
6.3.7 Program management
6.3.7.1 Changing the access rights
The following access rights can be defined in the overview displays:
r - Program is read only
w - Program is read/write
x - Program is executable
c - Program is copy-protected (cycle protection)
Machine manufacturer
The cycle protection (access right c) only functions in combination with the
"Cycle disable" interface signal, i.e. this function must be configured by the
machine manufacturer. Please refer to the manufacturer’s documentation.
