01.99 5 Parameters

SINUMERIK 840C, OEM Version for Windows (BA)

5-7

5.2.3 Entering PLC data in ASCII format

This function is not active as standard; it must be configured by the machine

manufacturer. Please read the machine manufacturer’s operator’s guide.

If this function is configured accordingly, you can input texts - as for example

tool designations - in plaintext into the control and edit them.

The following rules for operation apply:

• You cannot input more than 27 characters per line.

• With the INPUT key the current text is overwritten left-justified with the

contents of the input line.

• The text line is deleted with the CANCEL key.

Example of a configured display (not available as standard):

MILL

Automatic

Program reset

Mode grp:1

Channel :1

14:47

Test display for input in PLC texts

Text 1 DB59, from DW 0:

Text 2 DB59, from DW 30:

Text 3 DB59, from DW 60:

Text 4 DB59, from DW 90:

TURNING TOOL1

END MILL

TAP

Fig. 5-3 Input in ASCII format
