5.3.6.4 Scale
With this softkey you select the display menu for the scale data.
The values for scale factor and scale centre which are preset by programming
are displayed on the screen.
If the "Scale" function is to be activated, the axes have to be "enabled". This
serves on the one hand as a protective function and on the other as a means of
manipulation. (For example, you can enable only one axis and thus convert a
square into a rectangle).
The axis-specific enabling bits are included with the setting data bits (address
560*). For this, bit 2 serves to enable the NC axes.
5.3.6.5 General setting data bits (from SW 6.3 and higher behind setting bits)
You select GENERAL SETTING DATA BITS.
The display with the setting data bits of setting data 5000 to 5599 appears on
the screen.
The setting data from byte No. 5000 (up to 5799) are made up of 8 bits each: 0
to 7.
You can set the desired bit pattern for any byte in the range from 5000 to 5799
on the screen by way of an input screenform.
The following bits can be set:
SD 5000 bit 0,1,2 = 0 : Standard cycle up to UMS 02
= 1 : Standard cycle as from UMS 03
SD 5000 bit 7 = 0 : No calculation of the overflow
compensation
= 1 : Calculation of the overflow
compensation (see cycles description L84)
SD 5001 bit 0 = 1 : Display of workpiece-related actual
value system
SD 5001 bit 2 = 1 : Automatic saving (SAV) active
5001
0
0
000
001
7
6
543
210
Setting data
No.
Bit pattern for setting
data 5001
Possible bit states:
"0" = Bit is not set
"1" = Bit is set
Scale
Enabling bit
General
bits
Explanation of the
setting data structure:
(e.g. for setting data
(SD) 5001)
