01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-75
4.3.7 Saving programs
In the TEACH IN and AUTOMATIC modes you can transfer programs from
the working memory to the hard disk by means of the SAVE TO DISK and
SAVE UNDER softkey functions.
The machine area has been selected.
The TEACH-IN or AUTOMATIC mode has been selected
There is a part program in the working memory
Press the CORRECT PROGRAM softkey in AUTOMATIC mode.
The softkeys for saving part programs are to be found in this operating branch
because only here, i.e. in AUTOMATIC mode, can programs be altered. It is
therefore only possible to save programs here.
The softkeys for saving part programs are to be found in the operating mode
TEACH IN in the extension of the softkey bar which is called up with the ETC
key.
A program can be saved in two ways.
The program can either be saved in the current workpiece, that is the SAVE
TO DISK function or it can be saved using the DATA SELECTOR in any
(legal!) directory. This function is called SAVE UNDER.
The softkey is to be found in the basic display of PROGRAM CORRECTION
(operating mode AUTOMATIC).
Block
search
Tool path
simulation
Display
block
Mark
target block
Insert/
overwrite
Search Save to
disk
Preconditions
Correct
Program
Save
to disk
