4 Machine 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
4-76 SINUMERIK 840C, OEM Version for Windows (BA)
If the softkey SAVE TO DISK is pressed, the message "Store in workpiece?"
appears and the current directory and workpiece is displayed.
Fig. 4-34 Save 1
Press the softkey SAVE TO DISK again to save the program. While the
program is being saved the message "Transfer running" is displayed.
Note
If no workpiece is selected, only the path:
USER/LOCAL is offered.
The workpiece name must be entered via the keyboard.
The softkey SAVE UNDER is to be found in the menu extension of the
PROGRAM CORRECTION (AUTOMATIC mode). Now save using the
DATA SELECTOR.
Block
search
Tool path
simulation
Display
block
Mark target
block
Insert/
overwrite
Search Save to
disk
Cut . Save
under
Now press the SAVE UNDER softkey to display the data selector.
Save to
disk
Save
under
