01.99 5 Parameters
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
5-5
5.2.1 Selecting data
The procedure for selecting and editing is the same for all data types in this
NCK area. The following paragraphs describe the operator actions for editing
data using the operator panel keyboard.
Position in any input field with the cursor keys.
With these keys you page the screen display "down" and "up".
If you are searching for a specific item of data, enter the desired number via the
alphanumeric keyboard and then operate the SEARCH key (do not complete
your entry by pressing the INPUT key). If the value you are looking for is
within the selected data range, the cursor is positioned on this value.
Tip: Instead of using the SEARCH softkey you can also use the
select key for searching. Searching is, therefore, also possible when
no SEARCH softkey is offered on the softkey bar!
Operating
sequence
Search
