01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-25
4.2.5.2 Edit mode
Press the softkey and the following softkey bar is displayed::
Accept
position
Generate
block
Accept
MDA block
MDA
mode
Insert/
overwrite
Search Block struct.
settings
In edit mode there are no restrictions to editing and performing a teach-in at
any point in the program.
Note
In edit mode you can edit but not start a part program (NC start disable).
It is only possible to switch between the basic display and edit mode in RESET
state. This causes the program pointer to be reset to the start of the program
when you exit edit mode. Decoding begins with NC start.
TEACH IN is selected
You have selected a program with the softkey function SELECT
PROGRAM.
The program is in the RESET state, i.e. you must interrupt a running
program with the RESET key.
Select the edit mode.
The selected program is displayed in the program pointer and editor window.
Edit mode
Notes
Preconditions
Operating
sequence
Edit mode
