01.99 5 Parameters
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
5-31
5.3.6.12 Travel to fixed stop
Press the ETC key to extend the SETTING DATA softkey bar.
Press the softkey and the input screen is displayed with the configured axes.
You can use the function "Travel to fixed stop" to set-up defined forces for
clamping workpieces, e.g. tailstocks, sleeves, grippers, etc.
The clamping force for this function is entered in the input fields assigned to
the axes.
Input range: 0 to 999999
Tolerance: 0.1% of max. power setpoint (motor torque)
• The function "Travel to fixed stop" is an option.
• The function can be used for all axes.
• Spindles that are to travel to the fixed stop must first be switched to C axis
mode.
Machine manufacturer
The function "Travel to fixed stop" must be configured in the PLC user
program. Please refer to the documentation for the machine concerned.
■
Travel to
fixed stop
Note
