4 Machine 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
4-86 SINUMERIK 840C, OEM Version for Windows (BA)
The RECALL key is used to return to the display "Current block".
Machine manufacturer
The MD determines which axes and spindles are displayed in the respective
channel window (configured by machine manufacturer).
Display screens for more than two channels of a mode group can also be
configured by the manufacturer (WS 800A).
Machine manufacturer
The machine manufacturer defines the effect of keys and rotary switches of the
machine control panel on individual channels, axes and spindles. For example
the operating mode keys may have an effect on the display mode group (with
one machine control panel and several mode groups).
If you have any questions, please refer to the machine manufacturer’s
documentation.
■
