01.99 1 Introduction - SINUMERIK 840C and its Operation
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
1-9
Operating the RECALL key brings you back to the next higher menu level.
A red arrow in the extreme left softkey window indicates a return to the next
higher level:
With the ETC key, you can expand the softkey menu if an extension is
available.
If there is an arrow in the 7th softkey window (on the right),
this key is active.
You can press the Machine Area key to change directly from any area to the
Machine area.
A menu storage function has also been implemented in the NCK areas. The last
active menu of any NCK area (e.g. R parameter display) is automatically
saved.
If you then select a different NCK area (e.g. Machine), you can use the key
combination illustrated on the left to return to the same point in the starting
menu (R parameter display).
M
Menu storage
+
