6 Programming 01.99
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
6-59
Fig. 6-36 Copy MPF/SPF 02
Now press the softkey COPY - this copies program MPF100 to SPF1111.
The basic display for editing automatically reappears. SPF1111 is now listed in
the program overview.
A main program can also be copied to a subroutine (and vice versa). The
different program end (i.e. M17/M30/M02) should be checked if this is done.
MDA programs can be copied to main programs and subroutines - but not vice
versa (i.e. an MPF/SPF to an MDA program).
Note
The copy function described above is executed in the part program memory,
i.e. a copied program is not backed up when it is copied.
The program must be backed up using the softkey functions SAVE TO DISK
and SAVE UNDER.
Copy
Note
