8-10 SINUMERIK 840C, OEM Version for Windows (BA)
There are three types of display representation for alarm messages: Types A, B
and C.
Alarm display in sequence order (NCK alarms)
10243 ORD 5 X Illegal pulse multiplication RE
Approx. 40 characters for
explanatory text
(for single-line alarm)
max. 100 characters
(for two-line alarm)
Clearance cond.
Max. 5 characters for
ordinal number. The ordinal
number shows the order in
which the alarms have occurred.
Max. 6 characters for alarm number
Alarm display in block number order (cycle alarms)
3000 1 N0045 General programming error
CA
Approx. 38 characters for
explanatory text
Clearance cond.
(2 characters)
Max. 5 characters for block
number. E.g.: The error has occurred in block N0045.
Max. 5 characters for alarm number
1 character for channel number
PLC error and operational messages
6000 Hydraulic oil min. CA
Approx. 47 characters
for explanatory text
(for single-line alarm)
Clearance cond.
Max. 4 characters for
alarm number
Example of display
representation Type A:
Example of display
representation Type B:
Example of display
representation Type C:
