01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-5
Machine manufacturer
The machine tool manufacturer’s guide provides information on:
• Number of mode groups
• Number of machine control panels
• Assignment of machine control panels to the mode groups.
In each mode group you can select four operating modes JOG, TEACH IN,
MDA and AUTOMATIC.
If you activate the operating mode key, the corresponding operating mode is
selected, all other operating modes and functions are deselected.
The operating mode which is active is signalled and acknowledged by the
associated LED.
Machine manufacturer
Switchover of the machine control panel is configured by the machine
manufacturer. Please read the machine manufacturer’s specifications.
AUTOMATIC
Program reset
12:48
Mode grp.:1
Channel :1
Display of the currently selected operating modes
depends on the preset mode group
