4 Machine 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
4-22 SINUMERIK 840C, OEM Version for Windows (BA)
Fig. 4-5 TEACH IN
The basic display of the TEACH IN mode appears on the screen.
If no program is selected, enter a program name (identifiers MPF, SPF, %, L)
on the keyboard and press the SELECT PROGRAM softkey. If the program is
not stored in the NCK memory, a new program is created. The program is
displayed in the program pointer window. The first 3 blocks of an existing
program appear in the editor box.
Note
In the basic display of TEACH IN mode, you can start a part program using
NC START as in AUTOMATIC mode. It is not possible to set-up a program
here (teach-in, accept position, etc.).
When the "Help" key is pressed, information on the TEACH IN mode is
displayed on the screen.
You scroll through the information.
You will find a description of the "Additional machine functions" of the editor
and of "Program modification" in separate sections of this manual.
Select
program
i
Continue
Note
