Programming PLC Functions
4.6 Cross-channel status display
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
125
The dimensions of the SINUMERIK icons are as follows:
● Resolution 640x480: 16x16 pixels
● Resolution 800x600: 20x20 pixels
● Resolution 1024x768: 27x26 pixels
Note
When using the "Reversible spindles" or "Axis container" functions, the spindle status is
output before the spindle reversal or assignment to axis/spindle container, i.e. the spindle
number displayed under spindle status is the "logical" spindle.
Activating
The function is activated by MD 9052 SHOW_CHANNEL_SPANNING_STATE > 0. Changes
in MD 9052 take effect after a POWER ON.
This function is available if it is activated by means of the following machine data element:
9052 SHOW_CHANNEL_SPANNING_STAT
MD number Change cross-channel status display
Default value: 0 Min. input value: 0 Max. input value: 1
Changes effective after POWER ON Protection level (R/W) 4/1 Units: -
Data type: STRING Applies from SW version:
6.2
Significance Cross-channel status display:
0 = Display previous program status in header
1 = Display in program status line in header according to configuration in
Header.ini file.
SINUMERIK status display
The following 4 predefined displays are available:
1 Channel status (active, stopped, RESET) with superimposed spindle stop and feed
stop
2 Channel status (active, stopped, RESET) with superimposed feed stop
3 Channel status (active, stopped, RESET)
4 Spindle status Counter-clockwise direction, clockwise direction, spindle stop, spindle
halt M05
1 channel status
The channel status, feed stop, and spindle status are output as an icon at the display
position. The channel status icons can be superimposed with the "Spindle not enabled" or
"Feed not enabled" icon.
