Alarm/Machine data help
2.3 Machine data help
Online Help (HE1)
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
33
Structure of text file
PDF file without language code MD number Page
DROT.PDF 1000 1
DROT.PDF 1001 1
DROT.PDF 1002 1
... ... ...
Meanings of names
Name Meaning
N_NCK_GR.PDF General MD
C_NCK_GR.PDF Channel-specific MD
A_NCK_GR.PDF Axis-specific MD
S_NCK_GR.PDF Setting data
DISPL_GR.PDF Display MD
DROT_GR.PDF Drive MD, rotary
DLIN_GR.PDF Drive MD, linear
HYDRM_GR.PDF Drive MD, hydraulic module
2.3.2 Extending the machine data help
If additional user machine data are to be displayed in the MD help, these must be inserted in
directory C:\USER\HLP in the form of a PDF file and a TXT file of the same name.
Necessary files
• *.PDF: e.g., N_NCK_GR.PDF
• *.TXT: e.g., N_NCK_GR.TXT
1) Define jump labels in document
The jump labels must be identified by an index entry and a single-column index list
(right-justified page numbers) must be generated in the document (e.g., Winword) which
is to be displayed on the controller as a PDF.
